The T238 Lite 1100-BB Automatic Speedloader, a multi-system electric loader designed for efficiency on the field
The T238 Lite 1100-BB Automatic Speedloader is a motorized electric loader capable of feeding 6mm BBs into a wide range of airsoft loaders, including AEGs, GBBs, spring-powered bolt-action models, and gas cartridges for pump-action rifles. It's designed for regular players who want to reduce reload time between rounds, whether during team training, CQB, or simulation scenarios. Its compact size, precise counting features, and native multi-system compatibility make it a practical tool, engineered for demanding field use.
A design built for durability and compactness
The Speedloader Lite's body is made of PC/ABS, a material that combines rigidity and lightness for a total weight of 460 grams with the built-in battery. Its dimensions of 185 x 75 x 52 mm allow it to fit into a magazine pouch or radio pouch (see recommended products).
The central component of the feeding mechanism, the BB drive wheel, is made of 304 stainless steel. This material choice ensures high mechanical strength to withstand repeated loading cycles, whereas a polymer wheel would wear out more quickly under intensive use. The motor operates via a direct-drive system with gear reduction, delivering a torque of 17 kg·cm and a maximum thrust of 55 N, sufficient to feed heavy-duty spring-loaded magazines without excessive force.
Smart features for precise loading control
The Speedloader Lite's interface features an OLED screen and a 4-way directional pad with a center button, allowing you to navigate settings and view real-time battery voltage, the number of BBs loaded, and the current loading speed. The device achieves a maximum rate of 16 BBs per second at 12.6 V, which significantly reduces the time required to fill a high-capacity magazine.
Two operating modes are available. Preset mode allows you to set a fixed quantity of 1 to 999 BBs, with automatic shutdown once the target is reached. Five independent PRESET slots can be configured separately, a useful option for players who use multiple types of magazines with different capacities. An OFFSET slot also allows you to compensate for BBs lost at the adapter, with an adjustment range of 0 to 5 BBs. Dynamic manual mode triggers loading upon contact and stops when the trigger is released, providing total control without a preset value.
Jam management is fully automated: in the event of a jam, the motor shuts off in less than 0.01 seconds, and the system then attempts to clear the jam by reversing the motor over three successive cycles, without requiring any manual intervention. If the jam persists, an audible alert accompanies a "GEAR STALL" notification on the OLED screen. An empty-tank alert completes this system, signaled by a buzzer and on-screen display.
Multi-system compatibility and built-in power supply
The Speedloader Lite comes with four polymer adapter tips covering the main systems encountered in the field. Adapter A is compatible with AK- and AR-type AEG magazines and most standard formats, including the PTS EPM1 250-bbs magazine. Adapter B is designed for GBBR pump-action rifle magazines. Adapter C is suitable for spring-powered bolt-action magazines, and Adapter D supports GBB magazines from WE, GHK, MWS, and Tokyo Marui. Use is strictly limited to 6 mm plastic BBs: BBs of any other diameter and metal ammunition are incompatible and may damage internal components.
Power is supplied via a 2S or 3S LiPo battery with a T-shaped connector, with a maximum supported size of 102 × 19 × 16 mm. The Speedloader automatically detects the number of cells and adjusts its operation accordingly. Electronic protections round out the device: low- and high-voltage cut-off, thermal protection for the integrated ESC above 85°C with automatic power reduction, and a configurable standby mode that activates after 30, 60, 90, or 120 minutes of inactivity. Maximum power consumption is 40 W.
It is essential never to reverse the battery polarity and never to exceed 13 V: these errors cause irreversible damage to the motherboard. The operating temperature range is from -20 °C to +45 °C, covering all conditions encountered during outdoor gaming in both winter and summer.
Frequently asked questions (FAQ)
- What is the storage capacity and loading speed of the T238 Lite 1,100-ball Automatic Speedloader?
The hopper can hold approximately 1,100 6-mm BBs and offers a maximum loading speed of 16 BBs per second with a 12.6-V battery. You can program a specific quantity ranging from 1 to 999 BBs using Preset mode, which automatically stops once the set number is reached.
- What types of magazines are compatible with this electric speedloader?
This model comes with four polymer adapters for filling AEG magazines (AK, AR types), gas-powered shotgun shells, Spring Bolt Action magazines, and GBB magazines (WE, GHK, MWS, Tokyo Marui). It is also confirmed to be compatible with high-capacity magazines such as the PTS EPM1.
- What battery should be used to power the T238 Lite 1,100-BB Automatic Speedloader?
The device is compatible with 2S and 3S LiPo batteries using a T-Dean connector, with maximum dimensions of 102 × 19 × 16 mm. The system features automatic cell count detection and low-voltage cutoff protection to safeguard your equipment.
- How does the system protect the mechanism from BB jams?
In the event of a jam, the electronic protection shuts off the motor in less than 0.01 seconds and automatically performs three reverse cycles to unjam the stainless steel feed wheel. If the jam persists, an audible alert sounds and the message "GEAR STALL" appears on the OLED display.
- What is the purpose of the configurable OFFSET function on the OLED screen?
The OFFSET setting allows you to compensate for the natural loss of BBs that occurs when removing the adapter by adding 0 to 5 additional BBs to your programming. This ensures that your magazine contains exactly the desired number of BBs after loading.
- What materials are used in the construction of this speedloader?
The body is made of durable PC/ABS polymer, while the internal feed wheel is made of 304 stainless steel to ensure high mechanical durability. This robust design allows it to withstand a maximum thrust of 55 N during loading.
- Is the T238 Lite 1100-Ball Automatic Speedloader suitable for field use?
Yes, its dimensions of 185 × 75 × 52 mm allow it to be carried in a pocket like those featured in our recommended products. It's ideal for team training, intensive CQB, and military simulations requiring rapid reloading of multiple types of replica firearms.
- What accessories are included in the box?
The pack includes the Lite T238 1100-BB automatic speedloader as well as a complete set of four adapter tips (A, B, C, and D). An 1,100 mAh battery is also included.
Product content
1 x Lite Automatic 1100 bbs Speedloader T238
1 x Set of 4 adapter tips (A, B, C, D)
1 x 1100 mAh battery
1 x User manual
1 x Patch
Features
- Tool
- Brand T238
- Composition PC / ABS / 304 stainless steel
- Compatibility 6 mm BBs / 2S and 3S LiPo T-Dean / AEG, AK, and AR chargers / WE, GHK, MWS, and Tokyo Marui GBBs / spring / bolt action / gas cartridges for shotguns
- Dimensions 185 x 75 x 52 mm
